• ATV66D23N4 Schneider AC servo drive
1 1

Schneider

ATV66D23N4 Schneider

ATV66D23N4 Schneider

$7,407.67 USD
$8,714.91 USD $7,407.67 USD
Sale Ausverkauft
inkl. MwSt. Versand wird beim Checkout berechnet
Condition

Industrial AC servo-drive hardware supplied by Outdwella.

Main

Characteristic Value(s)
Range of Product Altivar 66
Product or Component Type Variable speed drive

Complementary

Characteristic Value(s)
Product destination Asynchronous motors
[Us] rated supply voltage 380...460 V - 10...10 %
Supply frequency 50...60 Hz - 5...5 %
Network Frequency 47.5...63 Hz
Phase 3 phase
Motor power kW 18.5 kW 380...460 V
Maximum Horse Power Rating 25 hp
Line current 44.7 A 380 V
35.6 A 460 V
Apparent power 23 kVA 400 V
Continuous output current 33 A 400 V
Output frequency 0…0.3 kHz
Nominal switching frequency 2.5 kHz
Switching frequency 0.5...4 kHz
8...16 kHz with current derating
Local signalling 1 graphic display terminal
Output voltage 400 V
Communication Port Protocol Modbus
Physical interface RS485 multidrop serial link
Transmission Rate 9.6...19.2 kbauds
Height 16.3 in (415 mm)
Width 9.2 in (234 mm)
Depth 9.6 in (245 mm)
Option card Communication card Profibus DP
Communication card CANopen
Communication card DeviceNet
Communication card Ethernet
Communication card Fipio
Communication card Uni-Telway
Communication card Interbus-S
Communication card Modbus Plus
Communication card AS-Interface

Ordering notes

  • New items are unused surplus stock and packaging condition may vary.
  • Used in Great Condition items have been previously installed or operated and are represented as serviceable used hardware.
  • Confirm the complete manufacturer part number, input voltage, output rating, motor compatibility, feedback interface, revision, and control-system requirements.

Outdwella is an independent reseller. Manufacturer names and part numbers identify compatibility and remain the property of their respective owners.
