ATVRU75N4 Schneider
ATVRU75N4 Schneider
No se pudo cargar la disponibilidad de retiro
Industrial AC servo-drive hardware supplied by Outdwella.
This regenerative unit is an option for variable speed drives of Altivar range. It has built in EMC filter compliant with standard IEC 61800-3. Its rated power is equal to 7.5kW. The main function of the ATV Regen product is to provide an option to regenerate energy back to the AC supply. Its protection index is IP20. Its maximum operating temperature is 50 °C. It weighs 6kg and its dimensions are 80mm wide, 337mm high, 175mm deep. It is designed for heavy braking applications such as material working, material handling and hoisting with easy setting. It conforms to international standards IEC 61800-3 and IEC 61800-5-1. This regen unit is compatible with ATV320, ATV340 and ATV900 drives. The product is delivered in one package. It can installed in either vertical or horizontal position. It is fully integrated inside Schneider Electricâs EcoStruxure Machine through DTM. It is possible to configure, control, and diagnose ATV320 drives directly in SoMachine and SoMove software by means of the same software brick (DTM).
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Altivar |
| Range Compatibility | Altivar Machine ATV340 Altivar Process ATV900 Altivar Machine ATV320 |
| Product or Component Type | Power module |
| Device Application | Energy regeneration |
| [Us] rated supply voltage | 380...500 V - 15...10 % |
| [Ue] rated operational voltage | 456...778 V DC |
| Kw Rating | 6.8 kW |
Complementary
| Characteristic | Value(s) |
|---|---|
| Network Frequency | 45...65 Hz |
| Phase | 3 phase |
| Fixing Mode | By screws |
| Maximum voltage drop at rated load | 3 % |
| Electrical connection | Control removable screw terminal block 0.5...1.5 mm², AWG 20...AWG 16 bottom) Power supply removable screw terminal block 2.5...4 mm², AWG 12...AWG 10 top) DC bus removable screw terminal block 2.5...4 mm², AWG 12...AWG 10 bottom) |
| Input current | 16.5 A 380 V AC voltage inputs continuous) 14.5 A 500 V AC voltage inputs continuous) 22.9 A 380 V AC voltage inputs transient for 60 s) 19.1 A 500 V AC voltage inputs transient for 60 s) |
| Input power | 6.8 kW 380...500 V AC voltage inputs continuous) 10.2 kW 380...500 V AC voltage inputs transient for 60 s) |
| Maximum DC bus voltage | 300...880 V DC |
| Output Current | 13.4 A 380 V AC continuous) 11.9 A 500 V AC continuous) 18.4 A 380 V AC transient for 60 s) 15.4 A 500 V AC transient for 60 s) |
| Width | 3.1 in (80 mm) |
| Height | 13.3 in (337 mm) |
| Depth | 6.9 in (175 mm) |
| Product Weight | 13.2 lb(US) (6 kg) |
Ordering notes
- New items are unused surplus stock and packaging condition may vary.
- Used in Great Condition items have been previously installed or operated and are represented as serviceable used hardware.
- Confirm the complete manufacturer part number, input voltage, output rating, motor compatibility, feedback interface, revision, and control-system requirements.
Outdwella is an independent reseller. Manufacturer names and part numbers identify compatibility and remain the property of their respective owners.
